Product Details
Place of Origin: China
Brand Name: UNMAG
Certification: ISO9001, IATF16949, ISO14001
Payment & Shipping Terms
Minimum Order Quantity: 100pcs
Price: As negotiation
Packaging Details: cartons,pallets
Delivery Time: 20-25days
Payment Terms: T/T L/C
Supply Ability: 100 tons per month for NdFeB magnet
Material: |
Neodymium Iron Boron |
Coating: |
Nickel,NiCuNi,Zinc,Epoxy Etc |
Shape: |
Block,Arc,Ring,Customized Shape Magnet |
Grade: |
N35-N52, 35M-50M, 35H-48H, 30SH-45SH... |
Application: |
New Energy Cars,Wind Power Generation,Servo Motors,Traction Motors |
Magnetic Orientation: |
As Customization |
Working Temperature: |
80~220°C |
Material: |
Neodymium Iron Boron |
Coating: |
Nickel,NiCuNi,Zinc,Epoxy Etc |
Shape: |
Block,Arc,Ring,Customized Shape Magnet |
Grade: |
N35-N52, 35M-50M, 35H-48H, 30SH-45SH... |
Application: |
New Energy Cars,Wind Power Generation,Servo Motors,Traction Motors |
Magnetic Orientation: |
As Customization |
Working Temperature: |
80~220°C |
Sintered Neodymium Magnets are made from Neodymium Iron Boron (NdFeB) alloy, a rare earth material, and are widely used in various industries such as automotive, aerospace, electronics, and instruments. These high-performance magnets feature strong magnetic field, superior corrosion resistance, and high temperature stability. They come in various shapes and sizes, including blocks, arcs, rings, and customized shapes. They can be coated with Nickel, NiCuNi, Zinc, Epoxy and other materials for increased durability. Furthermore, these magnets can be magnetized in a variety of orientations and directions to meet the customer's specific requirements. All our sintered neodymium magnets are certified according to ISO9001, IATF16949 and ISO14001 standards, guaranteeing a high quality and reliable product.
| Grade | Remanence | Coercivity | Intrinsic Coercivity | Max Energy Product | Working Temp | |||||
| (Br) | (HcB) | (HcJ) | (BH)max | Tw | ||||||
| KGs | T | KOe | KA/m | KOe | KA/m | MGOe | KJ/m³ | ℃ | ||
| N Series |
N35 | 11.7-12.2 | 1.17-1.22 | ≥10.9 | ≥868 | ≥12 | ≥955 | 33-36 | 263-287 | ≤80 |
| N38 | 12.2-12.5 | 1.22-1.25 | ≥11.3 | ≥899 | ≥12 | ≥955 | 36-39 | 287-310 | ≤80 | |
| N40 | 12.5-12.8 | 1.25-1.28 | ≥11.4 | ≥907 | ≥12 | ≥955 | 38-41 | 302-326 | ≤80 | |
| N42 | 12.8-13.2 | 1.28-1.32 | ≥11.5 | ≥915 | ≥12 | ≥955 | 40-43 | 318-342 | ≤80 | |
| N45 | 13.2-13.8 | 1.32-1.38 | ≥11.6 | ≥923 | ≥12 | ≥955 | 43-46 | 342-366 | ≤80 | |
| N48 | 13.8-14.2 | 1.38-1.42 | ≥11.6 | ≥923 | ≥12 | ≥955 | 46-49 | 366-390 | ≤80 | |
| N50 | 14.0-14.5 | 1.40-1.45 | ≥10.0 | ≥796 | ≥11 | ≥876 | 48-51 | 382-406 | ≤60 | |
| N52 | 14.3-14.8 | 1.43-1.48 | ≥10.0 | ≥796 | ≥11 | ≥876 | 50-53 | 398-422 | ≤60 | |
| M Series |
35M | 11.7-12.2 | 1.17-1.22 | ≥10.9 | ≥868 | ≥14 | ≥1114 | 33-36 | 263-287 | ≤100 |
| 38M | 12.2-12.5 | 1.22-1.25 | ≥11.3 | ≥899 | ≥14 | ≥1114 | 36-39 | 287-310 | ≤100 | |
| 40M | 12.5-12.8 | 1.25-1.28 | ≥11.6 | ≥923 | ≥14 | ≥1114 | 38-40 | 302-326 | ≤100 | |
| 42M | 12.8-13.2 | 1.28-1.32 | ≥12.0 | ≥955 | ≥14 | ≥1114 | 40-43 | 318-342 | ≤100 | |
| 45M | 13.2-13.8 | 1.32-1.38 | ≥12.5 | ≥955 | ≥14 | ≥1114 | 43-46 | 342-366 | ≤100 | |
| 48M | 13.6-14.3 | 1.36-1.43 | ≥12.9 | ≥1027 | ≥14 | ≥1114 | 46-49 | 366-390 | ≤100 | |
| 50M | 14.0-14.5 | 1.40-1.45 | ≥13.0 | ≥1033 | ≥14 | ≥1114 | 48-51 | 382-406 | ≤100 | |
| 52M | 14.3-14.8 | 1.43-1.48 | ≥13.0 | ≥995 | ≥14 | ≥1114 | 50-52 | 398-414 | ≤100 | |
| H Series |
33H | 11.3-11.7 | 1.13-1.17 | ≥10.6 | ≥844 | ≥17 | ≥1353 | 31-34 | 263-287 | ≤120 |
| 35H | 11.7-12.2 | 1.17-1.21 | ≥10.9 | ≥869 | ≥17 | ≥1353 | 33-36 | 263-287 | ≤120 | |
| 38H | 12.2-12.5 | 1.22-1.25 | ≥11.3 | ≥899 | ≥17 | ≥1353 | 36-39 | 287-310 | ≤120 | |
| 40H | 12.5-12.8 | 1.25-1.28 | ≥11.6 | ≥923 | ≥17 | ≥1353 | 38-41 | 302-326 | ≤120 | |
| 42H | 12.8-13.2 | 1.28-1.32 | ≥12.0 | ≥955 | ≥17 | ≥1353 | 40-43 | 318-342 | ≤120 | |
| 45H | 13.0-13.6 | 1.30-1.36 | ≥12.1 | ≥963 | ≥17 | ≥1353 | 43-46 | 326-358 | ≤120 | |
| 48H | 13.7-14.3 | 1.37-1.43 | ≥12.5 | ≥955 | ≥17 | ≥1274 | 46-49 | 366-390 | ≤120 | |
| SH Series |
30SH | 10.8-11.3 | 1.08-1.13 | ≥10.1 | ≥804 | ≥20 | ≥1592 | 28-31 | 233-247 | ≤150 |
| 33SH | 11.3-11.7 | 1.13-1.17 | ≥10.6 | ≥844 | ≥20 | ≥1592 | 31-34 | 247-271 | ≤150 | |
| 35SH | 11.7-12.2 | 1.17-1.22 | ≥11.0 | ≥876 | ≥20 | ≥1592 | 33-36 | 263-287 | ≤150 | |
| 38SH | 12.2-12.5 | 1.22-1.25 | ≥11.4 | ≥907 | ≥20 | ≥1592 | 36-39 | 287-310 | ≤150 | |
| 40SH | 12.5-12.8 | 1.25-1.28 | ≥11.8 | ≥939 | ≥20 | ≥1592 | 38-41 | 302-326 | ≤150 | |
| 42SH | 12.8-13.2 | 1.28-1.32 | ≥12.4 | ≥987 | ≥20 | ≥1592 | 40-43 | 318-342 | ≤150 | |
| 45SH | 13.2-13.8 | 1.32-1.38 | ≥12.6 | ≥1003 | ≥20 | ≥1592 | 43-46 | 342-366 | ≤150 | |
| 48SH | 13.7-14.3 | 1.37-1.43 | ≥12.6 | ≥1003 | ≥20 | ≥1592 | 46-49 | 366-390 | ≤150 | |
| UH Series |
30UH | 10.8-11.3 | 1.08-1.13 | ≥10.2 | ≥812 | ≥25 | ≥1990 | 28-31 | 223-247 | ≤180 |
| 33UH | 11.3-11.7 | 1.13-1.17 | ≥10.7 | ≥852 | ≥25 | ≥1990 | 31-34 | 247-271 | ≤180 | |
| 35UH | 11.7-12.2 | 1.17-1.22 | ≥10.8 | ≥860 | ≥25 | ≥1990 | 33-36 | 263-287 | ≤180 | |
| 38UH | 12.2-12.5 | 1.22-1.25 | ≥11.0 | ≥876 | ≥25 | ≥1990 | 36-39 | 287-310 | ≤180 | |
| 40UH | 12.4-12.8 | 1.24-1.28 | ≥11.3 | ≥915 | ≥25 | ≥1990 | 38-41 | 302-326 | ≤180 | |
| 42UH | 12.8-13.2 | 1.28-1.32 | ≥11.3 | ≥971 | ≥25 | ≥1990 | 40-43 | 318-342 | ≤180 | |
| EH Series |
30EH | 10.8-11.3 | 1.08-1.13 | ≥10.2 | ≥812 | ≥30 | ≥2388 | 28-31 | 223-247 | ≤200 |
| 33EH | 11.3-11.7 | 1.13-1.17 | ≥10.5 | ≥836 | ≥30 | ≥2388 | 31-34 | 247-271 | ≤200 | |
| 35EH | 11.7-12.2 | 1.17-1.22 | ≥11.0 | ≥876 | ≥30 | ≥2388 | 33-36 | 263-287 | ≤200 | |
| 38EH | 12.2-12.5 | 1.22-1.25 | ≥11.3 | ≥899 | ≥30 | ≥2388 | 36-39 | 287-310 | ≤200 | |
| AH Series |
30AH | 10.2-10.8 | 1.02-1.08 | ≥10.1 | ≥804 | ≥35 | ≥2706 | 28-30 | 223-247 | ≤220 |
| 33AH | 11.4-11.7 | 1.14-1.17 | ≥10.6 | ≥844 | ≥35 | ≥2706 | 31-33 | 247-263 | ≤220 | |
| 35AH | 11.7-12.1 | 1.17-1.21 | ≥10.9 | ≥876 | ≥35 | ≥2706 | 33-36 | 263-279 | ≤220 | |
| Certification | Application |
|---|---|
| ISO9001, IATF16949, ISO14001 | New Energy Cars,Wind Power Generation,Servo Motors,Traction Motors |
| Magnetic Orientation | Working Temperature |
| As Customization | 80~220°C |
| Grade | Shape |
| N35-N52, 35M-50M, 35H-48H, 30SH-45SH... | Block,Arc,Ring,Customized Shape Magnet |
| Coating | Material |
| Nickel,NiCuNi,Zinc,Epoxy Etc | Neodymium Iron Boron |
Sintered Neodymium Magnets, produced by UNMAG from China, are known for their unparalleled strength and durability. Available in a variety of shapes, from blocks and arcs to rings and customized shapes, these magnets are made to meet the specific needs of each application. They are also magnetically oriented as needed and coated with nickel, NiCuNi, zinc, epoxy, and other materials for added protection. The magnets are typically delivered in a carton box and can be shipped within 20-25 days.
Sintered Neodymium Magnets are used in a wide range of industries, such as new energy cars, wind power generation, servo motors, and traction motors. The magnets are certified to ISO9001, IATF16949, and ISO14001 standards, ensuring superior quality and safety. With their high-performance N50 neodymium iron boron composition, these sintered neodymium magnets offer unparalleled strength, making them the ideal choice for many applications.
Brand Name: UNMAG
Place of Origin: China
Packaging Details: Carton Box
Delivery Time: 20-25days
Working Temperature: 80~220°C
Coating: Nickel,NiCuNi,Zinc,Epoxy Etc
Shape: Block,Arc,Ring,Customized Shape Magnet
Grade: N35-N52, 35M-50M, 35H-48H, 30SH-45SH...
Material: Neodymium Iron Boron
UNMAG Sintered Neodymium Magnet is a Permanent Neodymium Magnet, which can be customized into Block, Arc, Ring or other shapes, and is widely used for the magnetic field of motors, wind turbines, electric vehicles, speakers, medical equipment, etc.
Grade: N35-N52, 35M-50M, 35H-48H, 30SH-45SH...
Working Temperature: 80~220°C
Coating: Nickel,NiCuNi,Zinc,Epoxy Etc
Packaging Details: Carton Box
Delivery Time: 20-25days
Place of Origin: China
Packaging and Shipping of Sintered Neodymium Magnet:
We package the sintered neodymium magnets in static-free bags, cardboard boxes, and plastic containers, depending on the size and quantity of the order. We provide transportation by air, sea, and land. We also offer door-to-door delivery services.
