ISO14001 Certified Sintered Neodymium Magnet for Industrial Motors

Brand Name:	UNMAG
Delivery Time:	20-25days

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001, IATF16949, ISO14001

Coating:

Nickel,NiCuNi,Zinc,Epoxy Etc

Magnetic Orientation:

As Customization

Grade:

N35-N52, 35M-50M, 35H-48H, 30SH-45SH...

Working Temperature:

80~220°C

Application:

New Energy Cars,Wind Power Generation,Servo Motors,Traction Motors

Shape:

Block,Arc,Ring,Customized Shape Magnet

Material:

Neodymium Iron Boron

Packaging Details:

Carton Box

Highlight:

ISO14001 certified sintered neodymium magnet

sintered neodymium magnet for motors

industrial motor neodymium magnet

Product Description

ISO14001 Certified Sintered Neodymium Magnet for Industrial Motors

Product Attributes

Attribute	Value
Coating	Nickel, NiCuNi, Zinc, Epoxy Etc
Magnetic Orientation	As Customization
Grade	N35-N52, 35M-50M, 35H-48H, 30SH-45SH...
Working Temperature	80~220°C
Application	New Energy Cars, Wind Power Generation, Servo Motors, Traction Motors
Shape	Block, Arc, Ring, Customized Shape Magnet
Material	Neodymium Iron Boron

Product Overview

When your motor or generator demands maximum flux density in a curved geometry, our ISO 14001 certified sintered neodymium iron boron (NdFeB) arc magnets deliver. Produced in an environmentally-managed facility, every arc segment meets tight ±0.05 mm tolerances and is 100% inspected for magnetic uniformity—ideal for servo motors, BLDC motors, wind-turbine generators, and magnetic couplings.

Key Features

Feature	Benefit
ISO 14001 Certified Plant	Traceable, eco-friendly production; REACH & RoHS compliant.
Arc Geometry	Perfect concentricity to reduce cogging torque in motors.
Grades N35-N52SH	11.7-14.8 kG remanence, Hcj up to 25 kOe for 150°C operation.
±0.05 mm Tolerance	Press-fit into rotors—no secondary grinding.
Multi-Layer Coatings	Ni-Cu-Ni, Zn, epoxy, parylene ≥ 500 h salt-spray life.
7-Day Prototypes	Laser-cut tooling, fast sintering cycle.

Technical Specifications

Property	Typical Range
Material	Sintered Nd₂Fe₁₄B
Grades	N35, N38, N42, N48, N50, N52, N35SH-N52SH
Remanence (Br)	11.7-14.8 kG
Coercivity (Hcj)	12-25 kOe
Max Operating Temp	80°C (N52) - 150°C (SH)
Arc Dimensions	OD 10-200 mm, ID 8-180 mm, thickness 2-30 mm, angle 5-180°
Tolerance	±0.05 mm, ±0.1° angle
Coating Options	Ni-Cu-Ni, Zn, black epoxy, parylene, Teflon
Certifications	ISO 14001, ISO 9001, IATF 16949, RoHS, REACH

Industrial Applications

Brushless DC (BLDC) motors - reduced cogging, higher torque.
Servo motors & actuators - precise positioning.
Wind-turbine generators - high flux density at low RPM.
Magnetic couplings & pumps - contactless torque transmission.
